PARTS CATALOGUE



Electric Units
3200E  Electric Insert Components



Data Sheet (in PDF format)




LEGALETT Part # Part Description   Add to Cart


7832 3200E Insert Assembly   Contact Legalett
7810 3200E Heating Element, 1.5 kW, 35.3 Ohms
7805 Return Air Thermostat, 3-Terminal
7826 Contactor
7807 Overheating Protector, 75 deg. Celsius
7808 Overheating Protector, 110 deg. Celsius
7048 Fan, 220V, 3 uF
7080 Transformer 230 V / 24 V
7083 Fan Fuse, 5A
7082 Transformer Fuse, 100 mA
7249 Capacitor, 3 uF
